Azerbaijan paper cup machine 12oz ripple double wall new tech

  • Azerbaijan paper cup machine 12oz ripple double wall wall
  • Price: $20,000
  • Model: 100S DW16,
  • Speed: 100 pcs/minute,
  • Cup size: 4~16oz,
  • 150~320gsm film coated paper, paper glossy print,
  • Circle spray water glue inside sleeve wall,
  • Water Glue (polyvinyl acetate emulsion),
  • Application: ripple double wall paper cup,
BASIC INFO Inquiry price

Info & Video of Azerbaijan paper cup machine 12oz ripple double wall wall

Watch Azerbaijan paper cup machine 12oz ripple double wall wall operation demo video

More vidoe list on youtube: https://www.youtube.com/@Feenot/featured

New tech Azerbaijan paper cup machine 12oz ripple double wall wall speed 100 pcs/min, make ripple double wall paper cups,wrap a jacket sleeve on inner cup, two layer paper cups, hot sale.

Firstly double wall ripple cup sleeve forming & adhesive machine is designed for market requirement, while use paper cups hold hot water coffee tea, one layer paper cup is hot and hurt finger, so we make a second wall help to prevent hot.

Double wall style: hollow paper cup sleeve machine, ripple paper cup sleeve machine,

Double wall cup machine is an automatic machine, after running a whole process as: wall sleeve fan feed and suck, hot melt glue spray (option), ultrasonic sealing (copper option ), lift wall to main mold, bottom fold, knurling, transfer to stick plate, spray a circle water glue (servo motor control, rotate a circle) inside the sleeve wall, suck cup down to sleeve, push the sleeve into cup rim space, discharge, count and collect.

While connect to the paper cup paking machine, make it full automatic, one packing machine online with 4, 6, paper cup bowl container machines.

Widely application: ripple wall paper cups, double wall paper cups, corrugated paper cups.

specification

  • Azerbaijan paper cup machine 12oz ripple double wall wall
  • Model: 100S DW16,
  • Speed: 100 pcs/minute,
  • Cup size: 4~16oz,
  • Top: 45~100 mm,
  • Bottom: 30~72 mm,
  • Height: 30~135 mm,
  • Material: 150~320gsm film coated paper, paper with glossy/varnish print,
  • Weight: 2000KG,
  • Machine:2350x960x1700mm,
  • Collector: 900 x 700 x 2100mm (against cup size )
  • Total power: 6KW,
  • Power: 380V 3-Phase 50/60 Hz,
  • 8 divide open cam ,
  • 8pcs Aluminium Alloy mold,
  • 25mm Thick Whole steel board structure base,
  • PLC + Sensors + Servo motor,intelligent, automatic oil system,
  • Sleeve wall welding by ultrasonic,
  • Auto bottom folded (hollow double wall cup sleeve),
  • Circle spray water glue inside sleeve wall,
  • Water glue stick the double wall sleeve and inner cup.
  • Water Glue (polyvinyl acetate emulsion),
  • Need Air (pressure:0.3~0.5Mpa, Output:300~500 L/m),
  • Application: ripple double wall paper cups bowl container,
